Connecting to video equipment – Eiki EIP-1500T User Manual
Page 27
24
When connecting video equipment with S-video output terminal (INPUT 3)
When connecting video equipment with video output terminal (INPUT 4)
S-video cable
(commercially available)
S-video output terminal
INPUT 3 terminal
DVD Player,etc.
2
1
INPUT 4 terminal
Video output terminal
Video cable
(supplied)
DVD Player,etc.
1
2
Connecting to Video Equipment
Video cable
Supplied
accessory
Note
• When you connect video equipment with a 21-pin RGB output (Euro-scart) to the projector, use a com-
mercially available cable that fits in the projector terminal you want to connect.
