Specifications A-8
RoamAbout Lightning Protector
RoamAbout Lightning Protector
The RoamAbout Lightning Protector is a surge arrestor that protects your sensitive
RoamAbout equipment from high-voltage currents caused by discharge and transients at
the antennas.
Table A-8 lists the specifications for the RoamAbout Lightning Protector.
Table A-8: Lightning Protector Specifications
Mechanical
Size
Height 69 mm (2.7 in)
Diameter 26 mm (1 in)
Weight 133 g (4.7 oz.)
Connectors
• FCC Countries Reverse Polarity-N (Male on both ends)
• ETSI Countries Standard-N (Female on both ends)
• France Standard-N (Female on both ends)
• Japan Standard-N (Female on both ends)
• Asia Pacific Standard-N (Male on both ends)
Operating Temperature -40°C to +85°C (-40°F to +185°F)
Electrical
Frequency Range 800-2500 MHz
Insertion Loss 0.2 dB
Surge Current 2000 Amp
Nominal Impedance 50 Ohms
