Low-Loss Antenna Cable
A-7 Specifications
Table A-6: Cable Specifications for the 15 Meter (50 Foot) Antenna
Table A-7: Cable Specifications for the 22 Meter (75 Foot) Antenna
Mechanical Specifications
Length 15 meter (50 ft)
Diameter 10 mm (0.4 in)
Weight 101.2 gram/meter (0.068 lbs/ft)
Bend Radius 25 mm (1 in)
Connectors 1
• FCC Countries Reverse Polarity-N (Female on both ends)
• ETSI Countries Standard-N (Male on both ends)
• France Standard-N (Male on both ends)
• Japan Standard-N (Male on both ends)
• Asia Pacific Standard-N (Male on both ends)
Operating Temperature -40°C to +85°C (-40°F to +185°F)
Electrical Specifications
Insertion Loss 0.22 dB/meter (6.8 dB/100 feet)
Total for this cable 3.5 dB
Mechanical Specifications
Length 22 meter (75 ft)
Diameter 10 mm (0.4 in)
Weight 101.2 gram/meter (0.068 lbs/ft)
Bend Radius 25 mm (1 in)
Connectors
• FCC Countries Reverse Polarity-N (Female on both ends)
• ETSI Countries Standard-N (Male on both ends)
• France Standard-N (Male on both ends)
• Japan Standard-N (Male on both ends)
• Asia Pacific Standard-N (Male on both ends)
Operating Temperature -40°C to +85°C (-40°F to +185°F)
Electrical Specifications
Insertion Loss 0.22 dB/meter (6.8 dB/100 feet)
Total for this cable 5.1 dB
