Specifications A-4
Vehicle-Mount Antenna
Vehicle-Mount Antenna
The RoamAbout vehicle-mount antenna can be mounted on vehicles, such as fork-lift
trucks, that need continuous access to networked data whether inside or outside of the
building. The following table provides the specifications for the vehicle-mount antenna.
Table A-3: Vehicle-Mount Antenna Specifications
Mechanical
Cable Size 250 cm (8 feet) Pigtail
Insertion Loss @ 2.4 GHz 3.3dB
Connectors
FCC Countries Reverse Polarity-N (Male)
ETSI Countries Standard-N (Female)
France Standard-N (Female)
Japan Standard-N (Female)
Asia Pacific Standard-N (Female)
Electrical
Frequency Range 2400-2438 MHz
VSWR (Voltage Standing Wave Ratio) 1.5:1
Nominal Impedance 50 Ohms
Gain 5 dBi
Half-Power Beamwidth NA
Polarization Vertical
Power Handling 100 Watts
Antenna Environment
Operating Temperature - 40°C (-40°F) to +60°C (140°F)
Relative Humidity Range 0-100%
Wind/survival (mph)
194 km/h (120 mph)
1
1 104 km/h (65 mph) with 1.25 cm (0.5 in) ice.
Wind rating 129 km/h (80 mph)
Wind load 202 km/h (125 mph)
