Antenna Options
1-10 Site Preparation
RoamAbout 14 dBi Directional Antenna
The directional antenna is a totally enclosed 16-element Yagi designed for point-to-point
communications. The antenna is normally mounted on a mast and vertically polarized. The
following table shows the components and part numbers in the RoamAbout directional
antenna kit. The numbers in the first column correspond to the numbers in
Figure 1-5 ,
which shows an example of a cabling configuration.
*European Telecommunications Standards Institute.
**128-bit encryption RoamAbout PC Card.
# Packaged
Kit/
Component Component Part Numbers by Domain
FCC ETSI* France Asia Pacific
FCC Asia Pacific
ETSI*
OUTDOOR
ANTENNA
KIT CSIED-AB CSIED-AB CSIED-AF CSIED-
AP-FCC CSIED-
AP-ETSI
1 Antenna CSIES-
AB-Y14 CSIES-
AB-Y14 CSIES-
AB-Y14 CSIES-
AB-Y14 CSIES-
AB-Y14
2 50-foot
Cable CSIES-
AB-C50 CSIES-
AB-C50 CSIES-
AB-C50 CSIES-
AB-C50 CSIES-
AB-C50
3 Pigtail
Connection CSIES-
AB-PT50 CSIES-
AB-PT50 CSIES-
AB-PT50 CSIES-
AB-PT50 CSIES-
AB-PT50
4 Access
Point CSIWS-AB CSIWS-AB CSIWS-AB CSIWS-AB CSIWS-AB
5 PC Card CSIBD-
AA-128** CSILD-AB CSILD-AF CSIBD-AB CSIBD-AB
6 Lightning
Protector CSIES-
AB-LP CSIES-
AB-LP CSIES-
AB-LP CSIES-
AB-LP CSIES-
AB-LP
