Page 53
UPS MAINTENANCE
EATON Powerware
®
5130 Rack/Tower UPS (1250–3000 VA) User’s Guide
S 164201730 Rev 2
www.powerware.com
47
How to Replace Internal Batteries
C A U T I O N
S
Pull the battery out onto a flat, stable surface. The battery is unsupported when you pull
it out of the UPS.
S
To ensure safety and high performance, use only batteries supplied by Eaton.
To replace the UPS internal batteries:
1.
Remove the UPS front cover. Press the button on the left side of
the cover and then pull the left side (see Figure 25).
1
2
Figure 25. Removing the UPS Front Cover
2.
Disconnect the internal battery connectors (see Figure 26).
1
2
Figure 26. Disconnecting the Internal Battery Connectors
