ADDITIONAL UPS FEATURES
EATON Powerware ® 5130 Rack/Tower UPS (1250–3000 VA) User’s Guide S 164201730 Rev 2
www.powerware.com
43
Customizing the UPS with the UPS Configuration Tool
To customize the UPS settings:
1. Download the UPS Configuration tool from www.powerware.com.
2. Follow the on-screen instructions for the Powerware 5130.
It is possible to modify the settings listed below (detailed
comments are available in the UPS Configuration tool).
Table 5. Main Output Options
Function Factory Setting Other Available Settings
Low-Voltage Models. Output voltage on
battery power 120 Vac 100/120/127 Vac
High-Voltage Models. Output voltage on
battery power 230 Vac 200/208/220/240 Vac
PW5130G3000-XL2U Models. Output
voltage on battery power 208V —
All Models. Overload alarm threshold 105% 30/50/70%
Table 6. Voltage Threshold Options
Low-Voltage Model Function Factory Setting Other Available Settings
High threshold for transfer to battery 151 Vac ±3% 141–153 Vac
Low threshold for transfer to battery 89 Vac ±3% 89–94 Vac
Fader activation threshold 132 Vac ±3% 127–138 Vac
Booster activation threshold 102 Vac ±3% 92–108 Vac
Maximum input-voltage range Disabled Enabled 1
High-Voltage Model Function Factory Setting Other Available Settings
High threshold for transfer to battery 294 Vac 271–294 Vac
Low threshold for transfer to battery 160 Vac 160–180 Vac
Fader activation threshold 265 Vac 244–265 Vac
Booster activation threshold 184 Vac 184–207 Vac
Maximum input-voltage range Disabled Enabled 2
1 Low threshold for transfer to battery is 70V.
2 Low threshold for transfer to battery is 150V.
