C o n f i g u r a t i o n a n d O p e r a t i o n
Page 12 Operator Instructions blueplanet XP10U H4 / H6 and XP10U H4 / H6 PSD
3.3.2 Menu structure
Icons used:
0 1 2 3 Menu level (0, 1, 2, 3) Password-protected menu
Display menu Submenu available
Option menu
Menu
level
Display/settings Action in this menu/meaning
Desktop Desktop  Press the right arrow key.
0 1 2 3 0 “Measurements” menu  Open the menu: Press the right arrow key or the OK key.
0 1 2 3 1 Generator Displays the DC-side voltage, amperage and power.
0 1 2 3 1 Grid Displays the AC-side voltage, amperage and power.
0 1 2 3 1 Unit temperature Displays the temperature in the inverter housing.
0 1 2 3 1 Yield counter
Displays the yield in kWh.
 Reset the counter using the “Reset” key.
0 1 2 3 1 Yield today Displays the yield of the current day up to now.
0 1 2 3 1 Total yield Displays the total yield up to now.
0 1 2 3 1 CO2 savings Displays the calculated CO
2
savings (in kg).
0 1 2 3 1 Oper. hours counter
Displays the duration of operation in hours.
 Reset the counter using the “Reset” key.
0 1 2 3 1 Oper. time today Displays the duration of operation on the current day.
0 1 2 3 1 Total op. time Displays the total operating time.
0 1 2 3 1 Log data view
 Open the menu: Press the right arrow key or
the OK key.
0 1 2 3 2 Daily view
Displays the recorded operating data graphically.
1. Select the measured value to be displayed.
Supported measured values:
• Grid power P(grid)
• DC power per string P(PV) 1-2
• DC voltage per string U(PV) 1-2
• Unit temperature
2. Select a date.
3. Press the OK key.
» The display shows the selected data.
 Press any key to return to the previous menu.
