Package Content:
SX8800-P2 MP3 Digital Player unit
Secure Digital (SD card) 32MB or higher
Power adapter 110v/ 240v AC to 12V DC 200-1000 ma
USB to SD card adapter to update the SD card via PC
RCA to RCA audio cord to connect to MOH port
User’s Manual
Connecting to a Computer:
Remove the SD card and insert it into an “SD card slot” normally found on most PC
or laptops (use the USB adapter in case the PC has USB port only)
This will be detected as “Removable Disk” , when you open “My Computer” or
“Windows Explorer”
Transferring files into SD card:
Select the file you want to transfer to the SD card and drag-and-drop it into the
“Removable Disk” that represents this device (right click on the file, copy, move the
mouse to the “Removable Disk” , right click there and paste)
The player will play all the .mp3 files one by one before it auto repeats from the 1 st
file, You may silence the .mp3 files you do not want to play by renaming them to
“file.ip3” or just keep one .mp3 file in the SD card, i.e. move or delete the extra files
you do not want to play from the SD card. After the file is transferred to SD card
allow 15 seconds for it to finish before removing the SD card.
Disconnecting from Computer:
⇒ Double click on the green arrow in the Taskbar located on the lower -right
side of the computer screen (Safely Remove Hardware)
⇒ Select “USB Mass Storage Device” from the list that appears then click
“Stop” then press “OK”
⇒ ⇒ ⇒ ⇒ When the “Safe to Remove Hardware” appears click OK and disconnect
the USB adapter or remove the SD card.
OUTPUT:
SX8800P2 has 3 output connectors, 8 Ω, 600 Ω & 3.5 mm. Use the 600 ohm output
in phone systems where a “hi-impedance” output works better. Use the 3.5 mm
stereo output if your MOH has a 3.5 mm stereo or mono jack or cable
.
Modes of playback: 1 to 99 tracks, device plays all the tracks one by one
and re-loops automatically, Silence any track by renaming it to filename.ip3 instead
of filename.mp3.
Single track
Multi track
SD CARD:
SX8800 can accept 32MB to 4GB SD cards available on the market.
Up to 256 hours of continuously playing audio time can be obtained using a 4GB SD
card.
Most SD cards have a lock that needs to be in unlock position (toward the edge) in
case the card needs to be accessed by the computer.
To remove the SD card, you may remove the power 1 st update it from your
PC/Laptop then insert back in or insert a new SD card. re-connect the power and the
playback automatically resumes in a few seconds.
Volume:
Turn the Volume control clock wise to increase the volume.
Turn the volume control counter clock wise to lower the volume.
SPEAKER:
Turn the speaker switch ON to hear audio from a speaker inside.
This is only for monitoring or testing the audio, the volume levels heard at this time
are not the actual audio levels available to the MOH port, be sure to readjust the
volume again when the calls are placed on Hold to ensure the proper and desired
audio volume levels.
STATUS LED light and other LEDS:
The Status LED will turn ON RED solid when the device is powered ON and working.
It blinks one time when the last track is played and it-re-loops.
In addition the LED lights located just below the SD card will be blinking to indicate
normal playback operation in progress or blink Red when a track change is being
performed
.
P2
P3
audio1.mp3
audio1.mp3 Audio2.mp3 ------ Audio99.mp3
To test the audio: Turn the speaker ON
the provided speaker can be used to hear the audio playback any time,
If you have a new SD card with new production in it, simply
“press in” the old SD card so it snaps out, insert the new SD
card and make sure it snaps in, the playback automatically
starts within 15 seconds.
