SMART TRAC CPU Card
14
••
Troubleshooting Your Smart Trac CPU Card Technical Manual
Possible Smart Trac Operating System Status and Error Messages
Message
Hexa-
decimal
Address
Meaning
FSTACK_UNDERFLOW 0x0000001B Std. Minor Fault -
INVALID_OPERAND 0x0000001C Std. Major Fault -
NEG_VALUE 0x0000001D Std. Minor Fault -
MALLOC_FAILED 0x0000001E Std. Major Fault -
INVALID_ACTION 0x0000001F Std. Major Fault -
IO_READ_FAILED 0x00000020 Std. Major Fault -
IO_WRITE_FAILED 0x00000021 Std. Major Fault -
CCALL_FAILED 0x00000022 Std. Major Fault -
STRING_OVERRUN 0x00000023 Std. Minor Fault -
NUM_SHIFTBITS_NEG 0x00000024 Std. Minor Fault -
INVALID_COERCION 0x00000025 Std. Major Fault -
INVALID_ADDR_MODE 0x00000026
INVALID_BIT_NUM 0x00000027
INVALID_DATASIZE 0x00000028
BIT_NUM_OUT_OF_RNG 0x00000029
INVALID_C_FUNC_PTR 0x0000002A
INVALID_LOWER_BND 0x0000002B
INVALID_UPPER_BND 0x0000002C
DATE_TIME_INVALID 0x0000002D
MSG_STRLEN_INVALID 0x00004000
USER_TASK_HUNG 0x00007FF8
NO_STARTUP_ROUTINE 0x00007FF9
BREAKPOINT_SET 0x00007FFA
OFFSET_OUT_OF_RNG 0x00007FFB Std. Major Fault -
TASK_OVERRUN 0x00007FFC Std. Major Fault -
TASK_RESTART_FAIL 0x00007FFD Std. Major Fault -
WATCHDOG_TIMEOUT 0x00007FFE Std. Major Fault -
OH_SHTUFF 0x00007FFF Std. Major Fault -
These following error codes are not OR'ed with 0x80000000.
Hardware Abstraction Layer Error Codes.
Message
Hexa-
decimal
Address
Meaning
HAL_SUCCESS 0x0000
HAL_STARTED 0x00020000
HAL_STOPPED 0x00020001
HAL_INVALID_CMD 0x00020002
HAL_NOTASKS 0x00020003
HAL_CREATETASKFAILED 0x00020004
HAL_TOO_MUCHDATA 0x00020005
HAL_NOSTACKMEM 0x00020006
HAL_FORCE_NOTENABLED 0x00020007
HAL_FORCE_ADDRINVALID 0x00020008
HAL_RTLIB_INDEX_ERR 0x00020009 Runtime library index
error
HAL_INVALID_IOHANDLE 0x00020010 Invalid I/O handle
HAL_CANNOT_SET_FORCED_MEM 0x00020011 Cannot set forced
memory
HAL_IO_LT_BIND_FAILED 0x00020012
HAL_DOWNLOAD_ACTIVE 0x00020013 Download active
HAL_PROG_RUNNING 0x00020014 An application program
is running
HAL_TASK_NOT_FOUND 0x00020015 Cannot find task in ???
HAL_MEM_CORRUPT 0x00020016 Memory corrupt
HAL_NOPROG_LOADED 0x00020017 No program loaded
HAL_START_IO_FAILED 0x00020018 Start of I/O failed
HAL_INVALID_ADDR 0x00020019 Invalid address
HAL_DOWNLOAD_INACTIVE 0x00020020 Download Inactive
