SMA SPEEDWIRE V.1.1 User Manual
Page 15
SMA Solar Technology AG
5 Connection
Installation Manual
SPW-WebconPB-IA-en-11
15
SB 3300-11, SB 3800-11
Figure 7: Overview of the connection area
Item
Description
A
Slot for Piggy-Back
B
Opening in the inverter enclosure with filler plug
C
Cable route to communication terminal
D
Communication terminal
E
Jumper slot for communication
