18
IK 5000 QUADRA-CHEK
Installation Instructions
Operating Instructions available at www.heidenhain.de
4. Installation
Read and understand the OEM system manufacturer Operating Instruction and
the PC manufacturer Operating Instruction before beginning the installation to
avoid the possibility of personal injury or death.
The safety of any system incorporating the use of this product is the
responsibility of the assembler or installer of the system.
Notice
Do not engage, or disengage any connections while the unit is under power.
Damage to internal components may result.
Interfaces
Interface connections Interface connections Interface connections
A X,Y and Z Encoder and foot switch
inputs
G IK 5000 card PCI connector to PC
motherboard
N Camera zoom control output
B
X,Y and Z axis CNC control outputs
H Q axis encoder input P
Comparator light source input for
optical edge detection
C
IK 5000 card connection to Flyout
connectors H and J
I
DIP switches for interpolation
settings
R
Comparator screen sensor input for
optical edge detection
D IK 5000 card connection to Flyout
connector K
J
Q axis CNC control output
T
Optical daughter board optical cables
through connectors P and R to
the comparator light source and
screen sensor
E
IK 5000 card power connector
K
Video light outputs
V TP200 daughter board connection to
flyout connector M
F
IK 5000 card connection to flyout
connector N
M Touch probe input W RS-232 PC motherboard connector
Minimum system requirements
Component w/o 3D profiling w/ 3D profiling
PC 2.66 GHz dual-core Pentium 2.8 GHz quad-core Pentium
Operating System
(OS) Windows XP
Windows Vista 32-bit
Windows 7 32-bit, 64-bit
Windows 8 32-bit, 64-bit
RAM 1GB 2GB
Available Hard Disk 500MB 1GB
PCI 1 PCI slot and 1 to 3 additional empty slots (depending on the
version)
Video Display Unit 1024 x 768 resolution
Windows users rights Administrator
