HEIDENHAIN TNC 620 (81760x-01) Cycle programming - Manual (Page 403)

MEASURE RIDGE WIDTH (Cycle 426, DIN/ISO: G426, software
option 17)
16.10
16
TNC 620 | User's Manual Cycle Programming | 3/2014
403
PGM stop if tolerance error Q309: Definition of
whether in the event of a violation of tolerance
limits the TNC is to interrupt program run and output
an error message:
0 : Do not interrupt program run, do not output an
error message
1 : Interrupt program run and output an error
message
Tool for monitoring Q330: Definition of whether
the TNC is to monitor the tool (see "Tool
monitoring", page 378). Input range 0 to 32767.9,
alternatively tool name with maximum of 16
characters
0 : Monitoring inactive
> 0 : Tool number in the tool table TOOL.T
