704 Tables and Overviews
1
8
.3 T
e
c
hnical Inf
o
rm
ation
Global Program Settings software option
Function for superimposing
coordinate transformations in
the Program Run modes „ Swapping axes
„ Superimposed datum shift
„ Superimposed mirroring
„ Axis locking
„ Handwheel superimposition
„ Superimposed basic rotation and datum-based rotation
„ Feed rate factor
Adaptive Feed Control software option (AFC)
Function for adaptive feed-
rate control for optimizing the
machining conditions during
series production „ Recording the actual spindle power by means of a teach-in cut
„ Defining the limits of automatic feed rate control
„ Fully automatic feed control during program run
KinematicsOpt software option
Touch-probe cycles for
automatic testing and
optimization of the machine
kinematics „ Backup/restore active kinematics
„ Test active kinematics
„ Optimize active kinematics
3D-ToolComp software option
3-D tool radius compensation
depending on the tool’s
contact angle „ Compensate the delta radius of the tool depending on the tool's contact angle at the
workpiece
„ Prerequisite: LN blocks
„ Compensation values can be defined in a separate table
Extended Tool Management software option
Tool management that can be
changed by the machine
manufacturer using Python
scripts. „ Mixed display of data from tool and pocket tables
„ Form-based editing of tool data
„ Tool usage and sequence list: component location diagram
Interpolation Turning software option
Interpolation turning „ Finishing of rotation-symmetrical shoulders through interpolation of the spindle with
the axes of the working plane
