650 MOD Functions
1
7.6 Ether
n
et Int
e
rf
ace
U The Internet tab currently has no function.
U Select the Ping/Routing tab to enter the ping and routing settings:
Setting Meaning
Ping In the Address: field, enter the IP number for
which you want to check the network
connection. Input: Four numerical values
separated by periods, e.g. 160.1.180.20. As an
alternative, you can enter the name of the
computer whose connection you want to check
„ Press the Start button to begin the test. The
TNC shows the status information in the Ping
field
„ Press the Stop button to conclude the test
Routing For network specialists: Status information of
the operating system for the current routing
„ Update button:
Update routing
