HEIDENHAIN TT 140 - Manual (Page 4)

Abmessungen . Dimensions . Dimensions . Dimensioni . Dimensiones
4
Tolerancing ISO 8015
ISO 2768 - m H
< 6 mm: ±0.2 mm
71
¬ 28
¬ 20
¬ 13.5
¬ 20
¬ 25
97
7.5
4.2
¬ 43
¬ 48 0
–0.2
¬ 20
¬ 34
13
1x45°
18
A
97
‰ 0.01 A
Š 0.03 A
7.5
4.2
6.7 37
70.9
21
¬ 29.5
M12
¬ 40 0
–0.1
Befestigung mit Spannpratzen
Mounting with fixing clamps
Fixation avec griffes de serrage
Fissaggio con graffette
Fijación con garras excéntricas
