PC Health Status Menu
Select
PC Health Status
from the CMOS Setup Utility menu and press
Enter
to display the PC Health Status menu.
Figure 10. PC Health Status Menu
All of the values shown in
Blue
are dynamic and change as the speed and
voltages of the various components change with system usage.
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F7:Defaults
SmartFan Function
[
Press Enter
]
VCC 3.3V 3.28V
CPU Vcore
1.19V
DIMM Voltage 1.65V
CPU VTT Voltage
1.23V
IOH Vcore 1.08V
VCC 4.96V
+12V 12.10V
3VSB 3.23V
VBT 3.15V
CPU temperature
-6
o
C
NB temperature
19
o
C
VREG temperature
22
o
C
System temperature
24
o
C
CPU Fan Speed 1337 RPM
Power Fan Speed 0 RPM
Chassis Fan Speed
0 RPM
Item Help
Main Level
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
