FEATURES AND CONTROLS
Instrument Cluster
Diagnostic Display Code Definitions
Diagnostic Codes
Component
Condition
SPN
FMI
EPS Models Only
Vehicle Speed Sensor
Data Valid But Above Normal
Operational Range - Most
Severe Level
84
0
Data Erratic, Intermittent Or
Incorrect
84
2
Abnormal Rate Of Change
84
10
Received Network Data In Error
84
19
System Power
Data Valid But Above Normal
Operational Range - Most
Severe Level
168
0
Voltage Above Normal, Or
Shorted To High Source
168
3
Voltage Below Normal, Or
Shorted To Low Source
168
4
Engine Speed
Data Valid But Above Normal
Operational Range - Most
Severe Level
190
0
Data Erratic, Intermittent Or
Incorrect
190
2
Received Network Data In Error
190
19
ECU Memory
Bad Intelligent Device Or
Component
628
12
Out Of Calibration
628
13
Calibration
Out Of Calibration
630
13
Steering Over Current Shut Down
Current Above Normal Or
Grounded Circuit
520221
6
Steering Excessive Current Error
Current Above Normal Or
Grounded Circuit
520222
6
Steering Torque Partial Failure
Condition Exists
520223
31
Steering Torque Full Failure
Condition Exists
520224
31
