SPECIFICATIONS
Clutching (850/850 SP)
*EBS models require no helix/spring adjustment
Clutching (850 High Lifter)
SPORTSMAN 850 / SPORTSMAN 850 SP
Front Suspension 850/850 SP: Dual a-arm with 9.2" (23 cm) travel
850 High Lifter: Dual a-arm with 7.4" (19 cm) travel
Rear Suspension 850/850 SP: Progressive rate with 10.2" (26 cm) travel
850 High Lifter: Progressive rate with 6.7" (17 cm)
travel
Transmission H/L/N/R/P
Gear Reduction, Low 5.034:1 (850/850 SP)
6.5:1 (850 High Lifter)
Gear Reduction, Reverse 4.508:1 (850/850 SP)
5.82:1 (850 High Lifter)
Gear Reduction, High 2.367:1 (850/850 SP)
4.48:1 (850 High Lifter)
Drive Ratio, Front 3.818:1
Drive Ratio, Rear 3.7:1
Tires/Pressure, Front 850/850 SP: 26x8-14 / 7 psi (48.3 kPa)
850 High Lifter: 29.5x9.5 / 7 psi (48.3 kPa)
Tires/Pressure, Rear 850/850 SP: 26x10-14 / 7 psi (48.3 kPa)
850 High Lifter: 29.5x9.5 / 7 psi (48.3 kPa)
Brakes, Front/Rear Single-Control Hydraulic Disc, All Wheel
Brakes, Auxiliary Foot-Activated Hydraulic Disc, Rear Wheel
Brake, Parking Hydraulic lock, all wheel
Headlight (Pod Models) 1 Single Beam (50 watt)
Headlight (Bumper) 2 Single Beam (50 watt)
Taillights 7 watts
Brake Light 27 watts
Instrument Cluster Digital/Analog
Altitude Shift
Weight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix*
Meters
(Feet)
0-1800
(0-6000)
24-63
PN 5632215
Orange
PN 7044279
Red/White
PN 3235088
58-66F 45°BA
PN 3235630
1800-3700
(6000-12000)
24-60
PN 5632216
Orange
PN 7044279
Red/White
PN 3235088
58-66F 45°BA
PN 3235630
Altitude Shift
Weight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix*
Meters
(Feet)
0-1800
(0-6000)
27-93
PN 5137856
Red/Black
PN 7043500
Black/White
PN 7044086
58-66FR 34°BA
PN 3235590
1800-3700
(6000-12000)
N/A N/A N/A N/A
