Page 40
38
FEATURES AND CONTROLS
Front Compartment
Open or remove the front rack, box or fan shroud to access the front
compartment components.
Fan Shroud (High Lifter)
Release the front fan shroud
latches and remove the shroud to
gain access to the front
compartment. Always reinstall
the shroud and secure the latches
before operating the vehicle.
Brake Fluid
Reservoir (auxiliary
foot brake)
Coolant
Bottle Cap
Electrical/Fuse/Relay
Battery
Radiator Cap
High Lifter Models
Radiator Cap
Cooler
Electrical/Fuse/Relay
Latches
