MAINTENANCE
Side Panel/Footwell Removal
1. Remove the seat before removing a side panel.
2. To remove a side panel or footwell, remove the fasteners securing it
to the frame. Lift the right side panel upward while removing it to
clear the shifter knob
Plastic Rivet
Hex Head Screw
Plastic Rivet
Touring Shown
