BAV-0808 Rev. 0
14
When programming the salvos, use the A/V Toggle button to program separate operations for video and
audio (breakaway). When using breakaway, remember that only the chosen layer (video and/or audio) will
be subject to switching when the setting is stored.
Example: If only the red light is lit in the A/V Toggle button when the next output is selected, the video
will be left unchanged for the previous output.
Disconnect output is programmed by pushing the selected input a second time, same as for normal
operation. Remember that the green (video) and/or red (audio) light in the A/V Toggle button must be lit,
in order to program, or disconnect. If not, an “unchanged” command is stored instead.
An example of how to program salvos on the BAV-0808 is shown hereunder.
Example:
The following configuration is applicable in the example:
• IN1: VGA Video from PC + PC audio
• IN2: VHS Video Player.
• IN3: DVD Player
• IN4: CD Player (Only Audio)
• IN5: Cassette Player (Only Audio)
• OUT1: VGA input on Projector + Audio Amplifier
• OUT2: Composite input (V+A) on Projector
The salvo’s we want are the following:
• F1: V
in
1 to V
out
2 + A
in
1 to A
out
1, (all other inputs shall be disconnected)
• F2: V/A
in
2 to V/A
out
1, (all other inputs shall be disconnected)
• F3: V/A
in
3 to V/A
out
1, (all other inputs shall be disconnected)
• F4: A
in
4 to A
out
1, (all other inputs shall be disconnected)
• F5: A
in
5 to A
out
1, (all other inputs shall be disconnected)
• F8: All inputs (V+A) to any outputs shall be disconnected
Step 1. Engage “Salvo Programming Mode” (See above for instructions).
Step 2. - Push “F1”,
- Push “OUT1”,
- Push “A/V Toggle”, and select A+V (Red + Green light),
- Disconnect all inputs, i.e. No inputs are lit,
- Push “A/V Toggle”, and select Audio (Red light),
- Push “IN1”
- Push “OUT2”,
- Push “A/V Toggle”, and select A+V (Red + Green light),
- Disconnect all inputs, i.e. No inputs are lit,
- Push “A/V Toggle”, and select Video (Green light),
- Push “IN1”
- Push “OUT3”,
- Push “A/V Toggle”, and select A+V (Red + Green light),
- Disconnect all inputs, i.e. No inputs are lit,
- Repeat the last three lines for all outputs 4 – 8 too.
Step 3. - Push “F2”,
- Push “OUT1”,
- Push “A/V Toggle”, and select A+V (Red + Green light),
- Push “IN2”
- Push “OUT2”,
