63
Technical Details
Chapter 7 provides electrical and mechanical specifications for the NV9607.
Topics
Power Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
NV9607 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Power Specifications
NV9607 Power Specifications
Power Supply Specifications
The power supply is an Miranda PS0001-00:
Specification Detail
DC power External power supply: 12 VDC ± 10%, 5 A.
Power consumption < 21W
Regulatory UL listed and CE compliant.
Specification Detail
AC power 90–264 VAC (127–300 VDC), 47–447 Hz.
Inrush current < 50 A at 230 VAC, cold start, at 25 °C,
Input current < 2.0 A rms at 115 VAC; < 1.0 A at 230 VAC.
DC power < 60W, 12 VDC, 5 A (5.4 A peak), Regulation ±2%. Ripple < 120 mV.
Efficiency Efficiency > 80% at full load typical, 115 VAC.
Weight 1.085 lb (0.492 kg).
Regulatory UL listed and CE compliant.
