54 8925DMB-B and -U — Instruction Manual
Configuration Summary Table
Enable Fiber TX1 output
(SFP-13103G-M1DRX option required
for Fiber TX1)
Disable Enable or Disable
Video Output
Fiber Video Output
Fiber TX1 Enabled checkbox
N/A
Enable Fiber TX2 output
(SFP-13103G-M1DTX or
SFP-13103G-M1TRX option required for
Fiber TX2))
Disabled Enabled or Disabled
Video Output
Fiber Video Output
Fiber TX2 Enabled checkbox
N/A
Recall factory default parameters – –
User Settings/
Set Factory Defaults button
N/A
Recall factory names – –
User Settings/
Set Factory Names button
N/A
Table 11. Summary of Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
