Cabling
Cabling
Cabling to the 8925DMB-B or 8925DMB-U module is done on the
8900BVF-R rear module (balanced audio inputs) or the 8900UVF-R rear
module (unbalanced audio inputs).
The I/O Config web page shows the inputs and the outputs assigned to the
different connectors of the rear modules. Cabling of the rear module
depends on what fiber optic submodule option is installed as below:
• 8925DMB-B and 8925DMB-U without fiber optic submodule option
(electrical only),
• 8925DMB-B and 8925DMB-U with SFP-13103G-M1DRX (Dual Receiver
Fiber Optic)
• 8925DMB-B and 8925DMB-U with SFP-13103G-M1DTX (Dual Trans-
mitter Fiber Optic), and
• 8925DMB-B and 8925DMB-U with SFP-13103G-M1TRX (Transceiver
Fiber Optic).
The 8925DMB-B and the 8925DMB-U will accept any of the video stan-
dards listed in the input specifications in
Table 5 on page 48 .
Table 2 below gives the inputs and the possible video output connections
for the 8925DMB rear modules. The cabling is illustrated in Figure 5 on
page 18 for the 8900VBF-R rear module and Figure 6 on page 18 for the
8900UVF-R rear module.
Table 2. 8925DMB Rear Cabling
Option
Video Inputs
Coax
Audio Outputs Video Outputs
Reclocked Video
Output
Optical Inputs Optical Outputs
Without optical option J9 J1, J2, J3, J4 J5, J6, J8 J7
With Dual Receiver J9 J1, J2, J3, J4 J5, J6, J8 J7 Fiber 1 or Fiber 2
With Dual Transmitter J9 J1, J2, J3, J4 J5, J6, J8 J7 Fiber 1 and Fiber 2
With Transceiver J9 J1, J2, J3, J4 J5, J6, J8 J7 Fiber 1 Fiber 2
