8920DAC Instruction Manual 15
Specifications
Specifications
Table 5. 8920DAC Specifications
Parameter Value
Digital Input
Signal type AES-3 id-1992, transformer coupled, loop-through
Number of inputs 1 loop-through
Connector type 75 Ω BNC
Common mode range +12/-7 V
Differential voltage range 200 mV to 12 V p-p
Sampling rates 32 kHz, 44.1 kHz, 48 kHz
Input return loss >15 dB (100 kHz to 10 MHz)
Maximum jitter <200 ps RMS
Outputs
Number of outputs 1 stereo (two-channel)
Signal type Balanced analog audio
Signal level for full-code input +14 to +24 dBu max
Output impedance 50 Ω single-ended, 100 Ω differential
Connector type Terminal block through BNC adapter board
Drive capability +24 dBu into 10 k Ω
Performance (24 dBu into 10 k Ω load)
Signal-to-noise ratio >107 dB unweighted 22 kHz filter, >110 dB “A” weighted
THD+noise (20-22 kHz) <0.004%, 22 kHz filter, +24 dBu/10 k Ω /7.5 nF
Interchannel crosstalk <-100 dB, 20 Hz to 20 kHz
Intermodulation distortion <0.006%, CCIF two-tone test, 19 kHz and 20 kHz tones
Frequency response ±0.1 dB, 20 Hz to 20 kHz
DC offset <± 1 mV
De-emphasis 50/15 µsec, automatic
Delay (input to output) 650 µsec
Environmental
Frame temperature range 0 to 45 degrees C
Operating humidity range 10 to 90% non-condensing
Non-operating temperature -10 to 70 degrees C
Mechanical
Frame type 8900 Series
Power Requirements
Supply voltage ±12 V
Power consumption < 3 Watts
