BrightEye 20

BrightEye-13

Analog Audio Outputs:
Number:

Four (selectable as inputs or outputs)

Type:

Balanced, transformerless

Impedance:

30 Ω

Max. Output Level:

24 dBu

Resolution:

24 bits, 128x Oversampled

Reference Level:

-10 dBu or +4 dBu

Frequency Response:

±0.1 dB, 20 Hz to 20 kHz

Crosstalk:

<102 dB

Dynamic Range:

>106 dB

General Specifications:
Size:

5.625” W x 0.8 “ H x 5.5” D
(143 mm x 20 mm x 140 mm)
including connectors

Power:

12-24 volts, 7 watts

Temperature Range:

0 to 40 degrees C ambient

Relative Humidity:

0 to 95% noncondensing

Due to ongoing product development, all specifications are subject to change.
