• Emph - the color of this box indicates the status of emphasis on the digital input
signal pair as follows:
Yellow indicates emphasis is present on the input and is being corrected.
Yellow/Gray (blink) indicates input emphasis is not being corrected or
incorrect deemphasis has been forced manually.
Black indicates no emphasis is detected on the input signal pair.
• Error - will indicate the presence of errors on the input signal pair as follows:
Red indicates minor errors exist on the input signal pair and have been logged.
Red/Gray (Blink) indicates major errors exist on the input signal pair and
have been logged.
Black indicates no errors exist on the input signal pair.
• Nxt Err - a left mouse-click on this box will clear the currently displayed error in
the Error Log (explained below). It will then display the next highest priority
error logged if it is present.
• Sampling Freq - displays the sampling frequency of the input signal pair. The
following sampling frequencies will be displayed:
48kHz
44.1kHz
44.056kHz
32kHz
Non-standard indicates the sampling frequency is not within 4% of any of the
above frequencies.
• Error Log - displays the most important error detected in the AES input signal
pair that occurred since the log was last cleared. Seven error messages, in order of
decreasing importance, may be displayed as follows. The first three of these are
treated as major errors.
No lock - input PLL is unable to lock to the AES input signal.
Bi-phase coding - a bi-phase coding error in the AES input signal is detected.
Parity - a parity error has been detected.
CRC - the CRC data in the AES input signal did not match the locally calculated
CRC (professional format only).
Confidence - the input signal eye opening has fallen below AES standard limits.
Invalid Error - the validity bit in the AES input signal has been set.
No error - no errors have been detected since the log was last cleared.
