2.4 SPECIFICATIONS
Camera
Sensor:
1/4” CCD SONY Super HAD
Effective pixels:
380.000 (NTSC), 440.000 (PAL)
Horizontal resolution:
520 TV lines (colour mode)
570 TV lines (b/w mode)
Sensitivity:
0,7 lux (F 1.8, 50 IRE – colour mode)
0,02 lux (F 1.8, 50 IRE – b/w mode)
0.005 lux ( DSS x 128)
Video output:
Composite 1 Vp-p (sync. negative)
S/N ratio:
over 50 dB
Sync. system:
internal
Electronic shutter:
1/60 ~ 1/120.000 NTSC, 1/50~ 1/120.000 PAL,
automatic (ESC) or manual
Digital Slow Shutter (DSS)
up to 128 x
White balance:
auto AWC / ATW mode, manual
Back light compensation:
adjustable 3 steps / OFF
Gain:
adjustable 3 steps / OFF
Flicker cancel:
ON / OFF
DNR Dynamic Noise Reduction:
adjustable 3 steps / OFF
Day/night switching:
IRC + b/w switching manual / automatic
Lens
Zoom ratio:
10x optical autofocus zoom
(+10x digital zoom, max. 100x)
Focus length:
f 3,8 (wide) ~ 38 (tele) mm
Aperture:
F 1.6 (wide) ~ F 2.8 (tele)
Viewing angle:
51.2° (wide end) to 5.58° (tele end)
Minimum object distance:
1,5 m
Focusing method:
auto, one-push AF, manual
Communication
Communication:
RS-485 simplex 2 wire
Built-in protocols:
EverFocus / Pelco-P / Pelco-D , setup by DIP switch
Baud rate:
2400 / 4800 / 9600 bps, setup by DIP switch
Speed dome address range:
1 ~ 255, setup by DIP switch
Alarm
Alarm:
3 inputs, 1 output, with tour / position auto triggering
PTZ / functionality
Horizontal rotation range:
360° unlimited rotation
Tilt rotation range:
90° with auto flip function
Auto pan, 2 points scanning:
adjustable speeds, adjustable end stops
Auto pan speed:
2, 6, 12, 30, 60, 120
o
/ second
Auto pan dwell time (A-B points):
1,3,5,10,30,45 s
Preset positions:
64
Preset tours:
1 tour with first 16 positions, 4 group tours with 4 positions each,
1 tour with individual setup up to 32 positions
Dwell time at preset position:
1 ~ 255 s
Pattern:
4 x pattern with up to 800 movements / 600 s PTZ recording each
Running to position speed:
up to 240° / sec.
Manual pan / tilt speed:
0,5° ~ 240° / sec.
Position accuracy:
0.225°
