Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distributor.
Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment. Then
determine the Part Number (not the Index Number) and the Description of each part from the following appropriate illustration and list. Be sure to give
all this information.
Applaince Model Number
Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62220-2623
HOW TO ORDER REPAIR PARTS
Index Part
No. Number Description
CHG-VF AND CHR-VF PARTS LIST
1 R-6477 CHIMENEA STACK CASTING
ASSEMBLY - RED
(INCLUDES STACK CASTING,
R-6475 KNOB - RED, R-6473
CAP - RED)
1 R-6478 CHIMENEA STACK CASTING
ASSEMBLY - GREEN
(INCLUDES STACK CASTING,
R-6476 KNOB - GREEN, R-6474
CAP - GREEN)
2 R-6641 MOUNTING RING - RED
2 R-6642 MOUNTING RING - GREEN
3 R-6479 CHIMENEA BODY CASTING
ASSEMBLY - RED
(INCLUDES BODY CASTING
- RED AND R-6641 MOUNTING
RING - RED)
3 R-6480 CHIMENEA BODY CASTING
ASSEMBLY - GREEN
(INCLUDES BODY CASTING
- GREEN AND R-6642
MOUNTING RING - GREEN)
4 R-6405 LEGS WITH RUBBER FEET
- RED (3 REQ’D)
4 R-6406 LEGS WITH RUBBER FEET
- GREEN (3 REQ’D)
5 R-6481 CHIMENEA DOOR
NS R-6643 BLOCK OFF PLATE
Index Part
No. Number Description
Attention: When ordering parts, it is very important that part number and description of part coincide.
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
PARTS LIST
CHBR-16
6 11538 REAR LOG SUPPORT
7 P-200 ORIFICE FITTING
8 P-181 ORIFICE - NAT
8 P-182 ORIFICE - LP
9 R-5676 AIR SHUTTER - NAT
9 R-5675 AIR SHUTTER - LP
10 R-3624 PILOT - NAT
10 R-3623 PILOT - LP
11 11285 BURNER SUPPORT - LEFT
12 12347 BURNER ASSEMBLY - NAT
12 12348 BURNER ASSEMBLY - LP
13 11948 BURNER SUPPORT - RIGHT
14 11947 BURNER SUPPORT PLATE
ASSEMBLY
15 R-4323 GAS VALVE - NAT
15 R-4324 GAS VALVE - LP
16 12975 COVER PLATE
17 R-3436 REMOTE/OFF/ON SWITCH
NS R-4579 WIRE HARNESS
NS 11951 TUBING - VALVE TO PILOT
NS 11952 TUBING - VALVE TO BURNER
NS 11833 PILOT SHIELD
NS 16001 HARDWARE KIT
NS 15998 ROCK WOOL
NS 11788 DECORATIVE ROCK
NS 12389 CERAMIC MEDI A
