Specifications are subject to change without notice.
specifications
Video
Gain ...................................................... Composite video and Y of S-video: -1 dB to +3 dB
(x0.9 to x1.4), adjustable
C of S-video: 0 dB to +10 dB (x1 to x3), adjustable
Equalization ............................................ 0 dB to +7 dB (x1 to x2) at 5 MHz, adjustable
Bandwidth (Y of S-video) ........................ 185 MHz (-3 dB)
Output cable driving distance ................. Up to 1000' (300 m) with Extron MHR cable
Video input
Number/signal type
CVEQ 100 Series ................................. 1 composite video
SVEQ 100 Series .................................. 1 S-video
Connectors
CVEQ 100 ........................................... 1 female BNC
CVEQ 100 D, CVEQ 100 AAP, CVEQ 100 MAAP
1 female RCA
SVEQ 100 ............................................ 2 female BNC
SVEQ 100 D, SVEQ 100 AAP, SVEQ 100 MAAP
1 female 4-pin mini DIN
Nominal level ......................................... 1 Vp-p for Y of S-video, and for composite video
(including sync)
0.3 Vp-p for C of S-video
Minimum/maximum levels
CVEQ 100 Series ................................. 0.4 to 2.0 Vp-p with no offset at unity gain
SVEQ 100 Series .................................. For Y: 0.4 to 2.0 Vp-p with no offset at unity gain
Impedance ............................................. 75 ohms
Return loss .............................................. <-25 dB @ 0 to 5 MHz
DC offset (max. allowable) ...................... 4.0 V
Input coupling ........................................ AC
Video output
Number/signal type
CVEQ 100 Series ................................. 1 composite video
SVEQ 100 Series .................................. 1 S-video
Connectors
CVEQ 100 ........................................... 1 female BNC
CVEQ 100 D, CVEQ 100 AAP, CVEQ 100 MAAP
1 female BNC attached via 4" pigtail
SVEQ 100 ............................................ 2 female BNC
SVEQ 100 D, SVEQ 100 AAP, SVEQ 100 MAAP
2 female BNC attached via 4" pigtails
Nominal level ......................................... 1 Vp-p for Y of S-video, and for composite video
(including sync)
0.3 Vp-p for C of S-video
Minimum/maximum levels ..................... 0.4 to 2.0 Vp-p (follows input)
Impedance ............................................. 75 ohms
Return loss .............................................. -30 dB @ 5 MHz
DC offset ................................................ ±5 mV with no input signal
Floating: +0.1 to -0.6 V, depending on input
signal content
Sync
Standards ............................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Audio
Gain ...................................................... Unbalanced output: 0 dB; balanced output: +6 dB
Frequency response ................................ 20 Hz to 20 kHz, +0.05 dB, -0.0 dB
THD + Noise ........................................... 0.015% @ 1 kHz at nominal level
S/N ...................................................... >100 dB at maximum output (unweighted)
Stereo channel separation ....................... >80 dB @ 1 kHz
Output cable driving distance ................. Up to 1000' (300 m) with Extron SHR cable
Audio input
Number/signal type ................................ 1 stereo unbalanced
Connectors ............................................. 2 RCA female
Impedance ............................................. 20k ohms unbalanced, DC coupled
Nominal level ........................................ -10 dBV (316 mVrms)
Maximum level ....................................... +8 dBu (2.5 V), unbalanced at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output
Number/signal type
CVEQ 100, SVEQ 100 .......................... 1 stereo, balanced/unbalanced
All other models .................................. 1 stereo or dual mono (switch-selectable),
balanced/unbalanced
Connectors ............................................. (1) 3.5 mm captive screw connector, 5 pole
Impedance ............................................. 50 ohms unbalanced, 100 ohms balanced
Nominal level ......................................... -10 dBV (316 mVrms), unbalanced; -2 dBu
(632 mV), balanced output
Maximum level ....................................... +9 dBV (2.8 V) unbalanced, +17 dBu (5.6 V)
balanced at 1% THD+N with a 10k ohm load
GenerAl
External power supply ............................ 100 VAC to 240 VAC, 50/60 Hz, external; to
12 VDC, 2 A, regulated
Power input requirements ....................... 12 VDC, 0.2 A
Cooling................................................... Convection, no vents
Mounting
Rack mount
CVEQ 100, SVEQ 100........................ Yes, with optional 1U, 9.5" deep rack shelf (RSU
129, part #60-190-01; RSB 129, 60-604-01); or
1U, 6" deep rack shelf (RSU 126, #60-190-10; RSB
126, 60-604-10); or VersaTools® 3.5" deep rack
shelf (RSF 123, #60-190-20; RSB 129, 60-604-20).
All other models ................................ No, but wall or furniture mountable
Furniture mount
CVEQ 100, SVEQ 100 .......................... Yes, with optional mounting kits
CVEQ 100 D, SVEQ 100 D ................... Yes, directly, or with a standard electrical wall box
or mud ring
All other models .................................. Yes, with optional AAP or MAAP mounting
faceplates
Enclosure type
CVEQ 100, SVEQ 100 .......................... Metal
CVEQ 100 D, SVEQ 100 D ................... Metal rear enclosure, plastic faceplate
CVEQ 100 AAP, SVEQ 100 AAP ............ Metal faceplate, open at rear
CVEQ 100 MAAP, SVEQ 100 MAAP...... Metal faceplate, metal rear enclosure
Enclosure dimensions
CVEQ 100 ........................................... 1.0" H x 4.3" W x 3.0" D (<1U high, quarter rack
wide)
(2.5 cm H x 11.0 cm W x 7.6 cm D)
(Depth excludes connectors. )
SVEQ 100 ............................................ 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack
wide)
(4.3 cm H x 11.0 cm W x 7.6 cm D)
(Depth excludes connectors. )
CVEQ 100 D, SVEQ 100 D
Faceplate .......................................... 2.6" H x 1.3" W x 0.1" D
(6.6 cm H* x 3.3 cm W x 0.3 cm D)
(Fits the opening in a 1 gang Decora faceplate.
*Height is 3.8" [9.5 cm], including mounting
tabs.)
(Depth excludes connectors. )
Device............................................... 2.7" H x 1.8" W x 0.75" D
(6.9 cm H x 4.6 cm W x 1.9 cm D)
(Depth excludes connectors; height excludes
mounting tabs.)
CVEQ 100 AAP, SVEQ 100 AAP
Faceplate .......................................... 1.4" H x 3.5" W x 0.1" D (3.6 cm H x 7.1 cm W x
0.3 cm D) (double space high AAP plate)
Device............................................... 1.1" H x 2.8 " W x 1.2" D (2.8 cm H x 7.0 cm W x
3.0 cm D) (Depth excludes connectors.)
CVEQ 100 MAAP, SVEQ 100 MAAP
Faceplate .......................................... 2.1" H x 2.2" W x -.1" D (5.3 cm H x 5.7 cm W x
0.3 cm D) (three space MAAP plate)
Device............................................... 2.0" H x 1.4" W x 1.2: D (5 cm H x 3.6 cm W x
3.0 cm D)
(Depth excludes connectors.)
Product weight
CVEQ 100, SVEQ 100 .......................... 0.7 lbs (0.3 kg)
All other models .................................. 0.2 lbs (0.1 kg)
Shipping weight
CVEQ 100, SVEQ 100 .......................... 3 lbs (2 kg)
All other models .................................. 2 lbs (1 kg)
Listings ................................................... UL, CUL
Compliances ........................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ...................................................... 30,000 hours
Warranty ................................................. 3 years parts and labor
NOTE: All nominal levels are at ±10%.
Model Version Description Part Number
CVEQ 100 Composite video and audio line driver .................... 60-812-01
SVEQ 100 S-video and audio line driver ................................... 60-813-01
CVEQ 100 D Decora Wallplate ..................................................... 60-867-01
SVEQ 100 D Decora Wallplate ..................................................... 60-868-01
CVEQ 100 AAP AAP Module - Black ................................................. 70-663-02
CVEQ 100 AAP AAP Module - White ................................................ 70-663-03
SVEQ 100 AAP AAP Module - Black ................................................. 70-664-02
SVEQ 100 AAP AAP Module - White ................................................ 70-664-03
CVEQ 100 MAAP MAAP Module - Black .............................................. 70-667-02
CVEQ 100 MAAP MAAP Module - White ............................................ 70-667-03
SVEQ 100 MAAP MAAP Module - Black .............................................. 70-668-02
SVEQ 100 MAAP MAAP Module - White ............................................ 70-668-03
