exceeded. Status indications are described in the NET and DTE Status fields.
Status indications are described in Table 4-4.
Near Loops
Displays the loop status of the near element.
Far Loops
Displays the loop status of the far element.
Configuration
Screen
The Configuration screens allow viewing and setting configuration parameters for
the network elements. Figure 4-10 shows the screens and where information about
them is located in the manual.
To send a new configuration to the unit, press Enter on one of the fields or exit the
screen. The underlined values are the factory default parameters.
Changing any of the configuration settings of an active 4051 causes a brief
synchronization loss.
Table 4-4 Status Indications
Status
Description
-------
No status is available
OK
No errors are currently detected.
LOS
A loss of signal condition exists.
OOF
An out of frame condition exists or OOF codes are received.
OOS
Out of Service codes are received.
DTR
DTR from the DTE device is false.
igure 4-10 Configuration Menu
DDS Network
Parameters
DTE Port
Parameters
Alarm
Parameters
Management
Parameters
Summary
Configuration Menu
✍
