Triplett 1101a User Manual
Page 12
6:
FRONT PANEL
1)
Backlit LCD Display
2)
Backlight and Hold button
3)
Rotary Function / Range Selector Switch
4)
Transistor Test Jack
5)
COM Jack: Common (black) jack for all measurements
6)
10A Jack: Input for currents from 200mA to 10A
7)
V/Ω /mA / F Jack: Input for Voltage, Ohms, µA, mA,
and Temperature
12
