Electrical characteristics curves – Delta Electronics Series E48SH User Manual
Page 3
E48SH3R330_02162007
3
ELECTRICAL CHARACTERISTICS CURVES
Figure 1: Efficiency vs. load current for minimum, nominal, and
maximum input voltage at 25°C
Figure
2:
Power dissipation vs. load current for minimum,
nominal, and maximum input voltage at 25°C.
Figure 3: Typical full load input characteristics at room
temperature
0
0.5
1
1.5
2
2.5
3
3.5
4
30
38
46
54
62
70
78
INPUT VOLTAGE (V)
IN
PU
T
C
U
R
R
EN
T
(A)
