Model 208B FF (Flange Facer)
92-1495 : Orig. 100728
SETUP AND OPERATION
Always read the operating instructions carefully/completely before attempting to
operate the Model 208B FF.
When operating any/all Tri Tool Inc. equipment follow the ‘Note’ statements through
the manual for equipment safety and the ‘Warning’ and/or ‘Caution’ notes for opera-
tor safety.
A FRL (Filter/Regulator/Lubricator) is required to protect the warranty on all TRI
TOOL INC. air or hydraulic driven tools.
For Hydraulic Motors refer to their ‘Operator’s Manual’ for specifics.
All components should be cleaned and coated with a light film of oil prior to use.
Use a clean, non-detergent oil, preferably SAE 10 (90 SSU or lighter) or oil which is
specified for the air motor.
ATTACHING THE FF KIT TO THE 208B
Remove the three (3) tool holders and mandrel from the Model 208B
BEVELMASTER®.
Mount the Model 208B FF (Flange Facer) kit to the Model 208B BEVELMASTER ®
and attach it with the six (6) mounting screws provided.
Reinstall the mandrel.
Attach the two (2) tripper block assemblies to the side of the 208B
BEVELMASTER®.Position and clamp the Model 208B to the ID of the pipe.
