CUTTING SPEEDS
The surface cutting speed will be dependent on the type of material being faced.
When facing over a mounting hole pattern in a flange, machine speed should be
reduced to lessen the impact on the cutting edge of the Tool Bit and to prevent
ripping the edge of the holes.
Depth of cut recommendations:
Roughing cut: .030” (.76 mm) maximum depth.
Finish cut: .010” (.25 mm) depth
Tool Bit feed rate is dependent on the flange material and the type of finish required.
Roughing or record finish: .026” (.66 mm) feed (both trippers engaged)
Smooth finish: .013” (.33 mm) feed (one tripper engaged)
