Appendix: Specifications
79
servers (e.g., Web, FTP, Mail servers) on user’s local
network.
Support DMZ
UPnP IGD (Internet Gateway Device) with NAT
traversal capability
Static routes, RFC1058 RIPv1, RFC1723 RIPv2.
DNS Relay
ARP Proxy
Security Features PAP (RFC1334), CHAP (RFC1994) for PPP session
Firewall support IP packets filtering based on IP
address/Port number/Protocol type
Support DoS (Deny of Services) which detect & protect
a number of attacks (such as SYN/FIN/RST Flood,
Smurf, WinNuke, Echo Scan, Xmas Tree Scan, etc)
WEP (Wired Equivalent Privacy) encryption uses RC4 with
64/128 bit key length (for wireless ADSL router only)
Configuration and
Management Configuration and Management
User-friendly embedded web configuration interface
with password protection
Remote management accesses control
Telnet session for local or remote management
HTTP firmware upgrades via web browser GUI directly
Distribute IP addresses to end users via DHCP server
provided by ADSL router
SNMPv1/v2 agent with MIB-II, ADSL Line MIB
Hardware
Interface One RJ-11 port for ADSL connection
One RJ-45 port for IEEE 802.3/802.3u 10/100 Base-T
auto-sensing Ethernet connection
One USB port compliant to USB v1.1 for 12 Mbps
connection rate
One hidden reset button for restoring to factory default
settings
Regulatory
Approvals and
Compliance EMI: FCC part 15 Class B
Immunity:FCC part 68 Class B
Safety: UL, CE
Power Requirement
and Operation
Environment
Requirement
_
18 VDC, 1A
Power Consumption:
less than 10 Walt
Ambient Temperature: 0 to 45°C (32 to 113°F)
Relative Humidity:
20% to 90% (non-condensing)
Physical Dimensions: 149.7 mm(L) x 118 mm(W) x 38 mm(H)
Weight: 260g
