45
Accessories
78-204 5 TH WHEEL HITCH PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-516-18-100 Bolt 5 /
16
- 18 x 1 2
` HNTL-516-18 Lock Nut 5 /
16
- 18 2
2 HB-38-16-225 Bolt 3 /
8
- 16 x 2 1 /
4
2
3 78-352 Control Panel Mount 1
4 HST-14-20-075 Truss Head Machine Screw 1 /
4
- 20 x 3 /
4 (part of machine) 4
HNFL-14-20 Flange Whiz Lock Nut 1 /
4
- 20 (part of machine) 4
5 78-353 Hose Hold Down 1
6 HB-516-18-150 Bolt 5 /
16
- 18 x 1 1 /
2
1
HNTL-516-18 Lock Nut 5 /
16
- 18 1
7 HB-12-13-125 Bolt 1 /
2
- 13 x 1 1 /
4
4
HNTL-12-13 Lock Nut 1 /
2
- 13 4
8 78-391 Gooseneck 1
9 HNW-38-16 Wing Nut 3 /
8
- 16 1
HW-38 Washer 3 /
8
1
10 HNTL-38-16 Lock Nut 3 /
8
- 16 1
11 78-390 Ball Lock Arm 1
INSTALLATION INSTRUCTIONS
Use two people to install hitches.
1. Block both wheels so machine does not roll.
2. Use the jack that is part of the sweeper to raise or lower sweeper to comfortable working height.
3. Slide the gooseneck (Ref 8) over the tabs on the front of the sweeper frame. Hitch must be on the outside.
Use the four 1 /
2
- 13 x 1 1 /
4
bolts (Ref 7) on the outside and four lock nuts on the inside. Tighten all four
bolts.
4. Install the control panel mount (Ref 3) on the front of the gooseneck (Ref 8) as shown, using two 3 /
8
- 16 x
2 1 /
4
bolts (Ref 2). On the bottom bolt use lock nut (Ref 9) and just tighten snug. On the top bolt use the
3 /
8
washer and wing nut (Ref 10). Tighten both after adjusting for the proper position.
5. The control panel has all hose, wiring and throttle cable connected to it and the sweeper. The control
panel is wrapped and fastened to the front of the sweeper.
6. Remove the control panel from the sweeper, bring it forward with the hoses to the rear and the throttle on
the left hand side.
7. Fasten the control panel to the control panel mount with the four truss head machine screws
1 /
4
- 20 x 3 /
4
(Ref 4) and four flange whiz lock nuts 1 /
4
- 20.
8. Put the two handles onto the valve and tighten the lock nuts with the handles pointing forward.
9. Lay the hoses, wiring and throttle cable on top of the gooseneck and place the hose hold-down (Ref 5)
over the top. At the rear most hole on top of the gooseneck fasten the hose hold-down with 5 /
16
-18 x 1 1 /
2
bolt and lock nut (Ref 6).
Do not tow on public roads.
