25
Parts
BLOWER AND VACUUM HOUSING PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 15-492 Cap w/ Gauge 1
2 15-491 Gas Tank, 5 Gallon w/ Insert 1
3 78-439 Trap Door 1
78-403 Trap Door Lining 1
4 78-375 Blower Housing 1
78-436 Pipe Plug 1
78-402 Blower Lining 1
HWF-14-150 Fender Washer 1 /
4
x 1 1 /
2
32
5 18-338 Male Connector 2
6 18-269 Coupling 1 /
8
2
7 18-027 Nipple 1 /
8
x 2 2
8 78-223 Mounted Bearing (1 1 / 8 " Bore) 2
9 78-336 Vacuum Housing Shaft 1
10 HKSQ-14-100 Machine Key 1 /
4
x 1 /
4
x 1 1
11 HB-716-14-150 Bolt 7 /
16
- 14 x 1 1 /
2
8
HNTL-716-14 Lock Nut 7 /
16
- 14 8
12 HSTP-14-20-075 Phillips Truss Head Machine Screw 1 /
4
- 20 x 3 /
4
20
HSTP-14-20-100 Phillips Truss Head Machine Screw 1 /
4
- 20 x 1 12
HNTL-14-20 Top Lock Nut 1 /
4
- 20 32
13 HBFL-516-18-075 Flange Bolt 5 /
16
-18 x 3 /
4
11
HNFL-516-18 Flange Whiz Lock Nut 5 /
16
- 18 4
HNTL-516-18 Top Lock Nut 5 /
16
- 18 7
14 78-301 Balanced Fan 1
15 78-347 Spiral Spring Pin 2
16 15-020 Handle Grip 1
17 78-243 Sweeper Boot 1
18 HB-38-16-100 Bolt 3 /
8
- 16 x 1 2
HNFL-38-16 Flange Whiz Lock Nut 3 /
8
- 16 2
19 78-276 Vacuum Housing Support 1
20 78-257 Vacuum Housing 1
8803-80 Trim Black 1
21 78-293 Cover Plate 1
22 15-039 Fuel Valve 1
8800-82 Fuel Hose 1 /
4
x 82" 1
18-186 Hose Clamp 1
23 HB-14-20-075 Bolt 1 /
4
- 20 x 3 /
4
4
HWL-14 Lockwasher 1 /
4
4
HW-14 Washer 1 /
4
4
24 18-042 Reducer Bushing 1
25 78-378 Gas Tank Mount 1
HB-516-18-100 Bolt 5 /
16
- 18 x 1 2
HNFL-516-18 Flange Whiz Lock Nut 5 /
16
- 18 2
26 78-355 Splice 1
27 HLC-58 Loom Clamp 5 /
8
1
28 78-419 Bottom Lining Holder 1
29 78-411 Top Lining Holder 1
30 78-412 Wear Cover 1
31 78-433 Cover Plate Bolt Tab 1
HB-14-20-075 Bolt 1 /
4
- 20 x 3 /
4
1
HNTL-14-20 Lock Nut 1 /
4
- 20 1
32 HB-516-18-075 Bolt 5 /
16
- 18 x 3 /
4
1
HNTL-516-18 Lock Nut 5 /
16
- 18 1
33 78-440 Door Pivot 1
