Diagrams
HYDRAULIC PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 78-247 Hydraulic Hose (brush motor to valve) 2
2 78-413 Hydraulic Pump 1
3 23-006 Oil Filter 1
23-031 Filter Element (replacement only) 1
4 78-249 Hydraulic Hose (pump to valve) 1
5 78-250 Hydraulic Hose (return to tank ) 1
6 78-415 2-Bank Hydraulic Valve 1
7 78-246 Hydraulic Hose (rear hyd. cyl. to front valve) 1
8 78-248 Hydraulic Hose (front hyd. cyl. to rear valve) 1
9 13-584 Oil Tank 1
10 8917-14 Suction Hose 5 /
8
ID x 14 1
18-222 Hose Clamp 2
12 78-414 Hydraulic Motor 1
13 75-714 Hydraulic Cylinder 1
HYDRAULIC PRESSURES
Pump Displacement .4 in 3 /rev
Pump Input Speed (up to) 3600 rpm
Max. Operating Pressure 2500 psi
Max. Inlet Vacuum 10 in. Hg
Max. Case Pressure 80 psi
78-415 Hydraulic Valve (2 bank) 2500 psi
