Schematics
10-529 48-VOLT WIRE HARNESS
REF# PART# DESCRIPTION QUANTITY
1 10-526 Charge / Hour Meter 1
2 FORWARD/REVERSE
15-725
Mount Panel End 1
15-727 Switch Actuator 1
10-531 Switch Body 1
3 1-2-3 SPEED
15-729
Mount Panel Middle 1
15-727 Switch Actuator 1
10-514 Rocker Switch 1
4 10-521 Cone Drive Gear Box 1
5 10-519 48-volt Motor with Headband 1
6 14-490 Master Disconnect 1
7 10-523 Contactor 2
8 10-525 Trojan Battery 4
10-532 Battery Cable Kit 1
9 10-513 400 AMP Fuse 1
10 10-527 Controller 1
11 10-522 Foot Pedal 1
12 Brake Switch 1
13 14-292 Seat Switch 1
