Delfield
™
®
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858 Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
www.delfield.com
45
32
N
F
la
t T
op
Fr
on
t-
Br
ea
th
in
g
F
la
t
To
p
F
re
ez
er
B
as
e
Printed in the U.S.A.
DS4532N
01/08
Specifications
Model Number of
Shelves
Shelf Area Storage
Capacity
H.P. V/Hz/Ph Amps NEMA Plug Ship Weight
4532N 1 3.97ft 2 6.9ft 3 1/3 115/60/1 9.50 5-15P 280lbs/127kg
D4532N NA NA 2.7ft 3 1/3+ 115/60/1 12.00 5-15P 315lbs/143kg
1.21" [3.08]
CORD DIMENSIONS
1.95" [4.96]
TO EDGE OF DRAWER
NOSE OF UNIT 19.60" [49.77]
36.00" [91.40]
33.59" [85.31]
32.13" [81.61] 31.50" [80.01]
4.00" OR 6.00" DEEP PANS ON TOP
4.00" DEEP PANS ONLY ON BOTTOM
2.50" [6.30]
INSTALLATION NOTE:
Refrigeration system is designed so that air will flow under the unit, through the compressor
area and out the front of the unit. Any restriction to this air flow path will void the warranties.
PLEASE NOTE:
Air flow through the louver on the back of the unit is not necessary for operation, however, any
air which passes through the louver is beneficial.
4532N ISO VIEW
4532N Elevation View 4532N Right Side View
D4532N ISO View
D4532N Elevation View D4532N Right Side View
4/
./3%
!,4
3(%,&
).4%2)/2
4/
./3%
!,4
3(%,&
).4%2)/2
4/
./3%
!,4
3(%,&
).4%2)/2
4532N & D4532N ISO View
Delfield reserves the right to make changes to the design or specifications without prior notice.
1.21" [3.08]
CORD DIMENSIONS
1.95" [4.96]
TO EDGE OF DRAWER
NOSE OF UNIT 19.60" [49.77]
36.00" [91.40]
33.59" [85.31]
32.13" [81.61] 31.50" [80.01]
4.00" OR 6.00" DEEP PANS ON TOP
4.00" DEEP PANS ONLY ON BOTTOM
2.50" [6.30]
1.21" [3.08]
CORD DIMENSIONS
1.95" [4.96]
TO EDGE OF DRAWER
NOSE OF UNIT 19.60" [49.77]
36.00" [91.40]
33.59" [85.31]
32.13" [81.61] 31.50" [80.01]
4.00" OR 6.00" DEEP PANS ON TOP
4.00" DEEP PANS ONLY ON BOTTOM
2.50" [6.30]
