Place the brackets on
the rods and adjust
them so they are more
or less flat to each
other. Pro Tip: If you
are having difficulty with
this step, turn the
bracket to one side, slip
it on and turn it back.
Attach the wooden
motor mount block to
the brackets using the
hardware provided.
Put the bolts through
bracket, then through
the block, put the wash-
ers on the end of the
bolt.
Thread the threaded
knobs over the
washers. Do not tighten
the knobs until all the
bolts are through the
block.
The heads of the bolts
should be aligned in the
channel on the bracket.
The channel is to keep
the head of the bolt
from turning.
Insert the pins in both
bars in their holes at
the end of the bars.
Use the cord to attach
the pins to the bar for
storage.
Inflate chamber #1.
Insert the hose with the
adapter into the valve.
Use the Inflation Moni-
tor to check the inflation
progress. When done,
the blue Inflation Moni-
tor printed on the boat
should match the black
scale on the plastic In-
flation Monitor.
When done chamber
#1 should look like this.
This is the backup
chamber in the event
that the main chamber
develops a leak.
