Electrical connection
The fresh water station is fully wired in
the factory and is supplied ready to plug
in. All you need is a 230 V/50 Hz socket
with a 10 A or 16 A fuse.
Circuit diagram
In order to avoid the circulation
pump from running dry, the fresh
water station may only be plugged
in once it has been filled with heat-
ing water, flushed and bled.
NOTE
Before use, the fresh water station must
be filled and thoroughly and carefully
flushed.
All connections, particularly flat-sealing
connections, must be tested for leak
tightness and if necessary retightened.
When bleeding the system, note the
minimum system operating pressure, and
if necessary top up.
M
~
l/h
L
N
M
~
t
T
Flow switch
Circulation pump
Fresh water station Circulation pump
(customer-provided)
thermostatically
and/or
time-controlled
