REMKO
FRESH WATER STATION
Construction
Mixing valve for
limiting the
temperature
at the tap
Hot water
connection, 3/4"
internal thread
Plate heat
exchanger
Circulation pump
Gravity brake
(close after filling!)
Flow switch
through the secondary side to be heated
to domestic hot water temperature.
A mixing valve allows the temperature
of the domestic hot water to be limited
(to prevent scalding).
Due to heating water only being sup-
plied to the plate heat exchanger when
it is needed, the fresh water station is
not susceptible to the formation of scale
- even in very hard water areas.
A customer-supplied circulation pump
can be connected. This should not be
operated on a permanent basis, but
ideally after a time delay and using the
integrated tap recognition function.
Chilled water
connection, 3/4"
internal thread
Circulation pipe
Connection 1/2”
Circulation pipe
Connection 1/2”
