19
3. Each outer deck assembly has the opposite wing installed on it upon shipment.
Each outer wing frame must be removed and installed on the correct deck
before the outer wings can be properly installed.
4. Remove each cable tie holding the lift
pivot and lift shaft in place, allowing
them to rotate freely.
5. Remove the 5/8” x 8.5” bolt, springs,
bushing and hardware from the deck
frame in order to remove the wing.
6. Using a lifting device with a
minimum 100lb capacity, lift
each wing off of the outer decks.
7. Before installing the LH wing
onto the LH deck, remove the
inner deck shield in order to
access the lift shaft mounting
point.
