heard as indicated in the pictures below.
Labeling On Keytop
The multifunction security device is provided with an easy and durable
method for reminding the user of content programmed in each programmable
key. First preprint (or write) in each cell of the attached colored legend sheet
the “name” for each key. Stick each cell to the corresponding keytop and then
put on the transparent key cap from the accessories. In this way, the labeling
will be protected and resistant to scratch or rubbing.
When re-labeling is required, please use the attached key clip to hook up
the transparent key cap and change the label then re-cap.
KEYPAD PROGRAMMING
The programming of the keys above the numerical keypad in KP-100/
KP-100U or KP-110/ KP-110U and those beside the numerical keypad in KB-
4000 is in general the task of the system integrator and not the average end
user. For end user, please go to the chapter of “OPERATION GUIDE” of this
manual directly.
Utility Installation
In the Posiflex Product Information CD attached with Posiflex POS
terminal, there is a subfolder named as “\Drivers\KP” or “\Drivers\KP100” or
please download the keypad programming utility for KB-4000 / KP-100 / KP-
100U / KP-110/ KP-110U from our web site:
http://www.posiflex.com.tw/DriversDownload.asp.
In the above mentioned subfolder there are 2 further subfolders
“KBM40.xxx” and “KBW40.xxx” with “xxx” representing any number of the
utility revision. For operating system of MS-DOS or Win98 DOS box, please
execute “KBM40.xxx\INSTALL.EXE” to install the utilities “KBM.EXE” and
“RWM.EXE”. The “KBM.EXE” is a key-by-key programming utility for DOS
environment. The “RWM.EXE” is a special direct transfer utility under DOS.
Execute “KBW40.xxx\SETUP.EXE” to install the programming utility
“KBW.EXE” for KB-4000 / KP-100 / KP-110 in Windows OS. Please note
that for programming of KP-100U / KP-110U, only the “uKBW” utility is
Single key
Latching tab
Double key
Tab in the
guide hole
