8.Technical Specifications
22
8. Technical Specifications
The specifications below are based on the instrument having run for at least 30 minutes
continuously under the specified operating temperature.
Channel Fixed 5V/3.3V
DC Output Ratings
Voltage 0～30V 5V/3.3V
Current 0～3A 3A
Line Regulation
CV
≤0.01% + 3mV ≤3mV
CC
≤0.1% + 3mA
Load Regulation
CV ≤0.01% + 3mV ≤0.1%+3mV
CC ≤0.2% + 3mA
Noise and Ripple
(20Hz～7MHz)
CV ≤300 μVrms / 2 mVpp
≤300 μVrms
/ 2 mVpp
CC
≤3mArms
Settings Resolution
Voltage 1mV None
Current 1mA None
Settings Accuracy
（25℃±5℃)
Voltage
≤0.05% + 3mV
None
Current ≤0.1% + 3mA None
Read Back
Resolution
Voltage
1mV (＜10V)
10mV (≥10V)
None
Current 1mA None
Read Back
Accuracy
（25℃±5℃)
Voltage
≤0.05% + 3 digits
None
Current ≤0.1% + 3 digits None
