4.Quick Start
9
 User interface in Timer status
⑨ ⑩ ⑧
①
②
③
④
⑥
⑤
⑦
Figure 4-4 User interface in Timer status
① Set time of current output
② Left time of current output
③ Set values of voltage for Channel
④ Set values of current for Channel
⑤ Set values of voltage that will be output at the next fixed times
⑥ Set values of current that will be output at the next fixed times
⑦ Timer Status icon
⑧ The parameter number of the current output
⑨ Timer range
⑩ Output mode of timing output (Sequence / Loop)
4.2 General Inspection
After you get a new ODP3031 power supply, it is recommended that you should make a
check on the instrument according to the following steps:
1. Check whether there is any damage caused by transportation.
If it is found that the packaging carton or the foamed plastic protection cushion has
suffered serious damage, do not throw it away first till the complete device and its
accessories succeed in the electrical and mechanical property tests.
2. Check the Accessories
