PARTS LIST
FIREBOX MODELS VYGF33PRC AND VYGF33NRC
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 30 of this manual.
KEY
NO. PART NO.
DESCRIpTION QTY.
1 101357-03 Top Outer Casing 1
** Outer Casing 1
3 ** Right Front Side 1
4 ** Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 9
6 10439-01CK Top Front Louver 1
7 10171-03 Firebox Hood 1
8 ** Firebox Support
9 09930-0 Shoulder Screw 4
10 ** Firebox Top 1
11 101346-01 Outer Base 1
1 ** Firebox Wrapper 1
13 101514-01 Cover 1
14 M11084-6 Hex Screw, #10 45
15 110466-01 Bottom Louvered Door 1
16 10177-03 Screen Assembly 1
pARTS AvAILABLE — NOT SHOWN
101386-0 Louvered Door Hinge
101784-01 Magnet Catch
10307-01 Strike Plate
** Not a field replaceable part.
